2.0 IFP FRONT SHOCKS for TOYOTA SEQUOIA, 2008 to 2020 (2 in. to 3 in. lift)

Weight 58 lbs
Dimensions 40 × 12 × 16 in
Part Number

Product Line

TRUCKS

Vehicle Make

Vehicle Model & Year

Position

Primary Intended Use

Product Model

Body Diameter & Material

Type

Reservoir Configuration

Adjustments

Preload

Vehicle Geometry

Lift Range (vs. stock)

Factory Preset Lift (vs. stock)

Extended Length

N/A

Compressed Length

N/A

Stroke

N/A

Spring P/N

C12.5X406

Spring Rate

700 lb/in

Spring Length

16 in. (406mm)

Spring Inner Diameter (ID)

Spring Outer Diameter (OD)

Unit of sale (sold as)

sku

Increase the off-road capabilities while improving the comfort and handling of your Sequoia

The 2.0 IFP shocks provide the optimal combination of:

  • Firm and stable handling for driving on desert and fire roads (sports car feeling);
  • Plush compliance while off-road driving over washboard;
  • Strong ramping effect for extra bottom-out protection over large dips and washes;
  • Maximum articulation and traction for rock climbing.

BENEFITS

  • High-performance off-road capabilities
  • Improved handling and comfort for casual driving
  • Better traction
  • Provides leveling capabilities for better weight distribution
  • Increased protection against bottoming-out

RIDE ENHANCEMENTS

  • Spring setup optimized for each setup
  • Better attenuation of vibration, leading to major noise reduction in the cabin (much less squeak and rattle)
  • Damping characteristics optimized for each truck and setup, providing a smoother ride
  • Increased comfort in both on road and off-road conditions, especially over washboard and square-edge impacts
  • More stable and more predictable handling
  • Reduced front-end diving when cornering or braking
  • Reduced rear-end bucking and lifting
  • Increased damping and spring rate for better handling when towing or loading truck

TECHNICAL FEATURES

  • Massive 2.0 in. (46mm) hard-anodized aluminum body for cooler operation
  • Gas-pressurized design with internal floating piston to prevent cavitation and fading
  • Internal hydraulic valving optimized for each vehicle platform
  • Built from CNC-machined and forged aluminum parts, aluminum bodies and premium-quality internal components
  • Heavy-duty 5/8 in. (16mm) induction-hardened shaft
  • Triple sealing system with dust wiper, high-pressure step-seal and premium quality o-ring
  • Direct, bolt-on replacement that uses stock shocks location
  • Proprietary ultra-low friction, light viscosity semi-synthetic oil blend, ultra-resistant to high operating temperature
  • Coilover models use Elka’s durable high-tensile alloy springs or Eibach springs (depending on model & configuration)
  • Fully rebuildable using affordable replacements parts and springs, multiple replacement valving shim stacks available

The 2.0 IFP model is a simple bolt-on upgrade over OEM shocks. They are a gas-pressurized design with internal floating piston to help prevent cavitation and fading.

This configuration is for use exclusively with aftermarket lift kits or upper control arms to accommodate between 2 in. to 3 in. of lift.

Ride height at the front is preset from our factory at approximately 2.5 in. of lift for most setups, actual ride height may vary depending on wheels dimensions and lift kit or upper control arms used.

Package includes two (2) side-specific front shocks


ADJUSTMENT

  • Spring Preload
